Home / Air purification / eTree Ambient Air Purifier

02 • Air purification • Ambient air

Cleaner air where people breathe

eTree is a patented outdoor air purifier shaped like a tree. It draws in polluted street-level air, removes dust and fine particulates, and reports air quality live. One eTree does the air-cleaning work of about 20 trees.

Patent No. 422515Equal to 20 trees300 CFM per unitLive PM2.5, PM10, O₂ and CO₂ dataAbout 0.3–0.5 units of power a day
eTree ambient air purifier design
Pedestrians wearing masks on a polluted city street

The challenge

Millions breathe unsafe air on their way to work and school

1
Street-level exposurePedestrians, commuters and street vendors breathe traffic dust and smoke for hours every day.
2
Children most at riskSchool gates and bus stops are often the most polluted places children spend time.
3
Hard to prove progressCities need measured, local data to show their clean-air spending is working.

Our answer: eTree purifies air at street level and reports PM2.5, PM10, O₂ and CO₂ live from every unit.

Why choose it

Key benefits

Purifies air at street level

Cleans the air at the height where pedestrians, commuters and children breathe.

Data you can report

Sensors track PM2.5, PM10, O₂ and CO₂ so cities and companies can show measured results.

Very low running cost

About 0.3–0.5 units of electricity a day, with no filters to replace in the primary stages.

Designed for public spaces

A tree-like form that blends into roads, parks and campuses, on a 2.5 ft square footprint.

How it works

Three-stage purification

Air rises from the base to the top of the unit and is cleaned in three stages.

Polluted air inat the base
Cyclonecoarse dust into a tray
Corona dischargePM2.5, PM10 and carbon
Activated carbonozone and odours
Clean air outwith live monitoring
TestedIndependent
performance
test
Nov 2026

Independently tested technology

eTree, independently tested in the field

An esteemed technology institute carried out an independent third-party performance evaluation and technical audit of an eTree installed at a residential site in Bhandup, Mumbai, with 48 hours of continuous air-quality monitoring in October 2026. The unit was found satisfactory, its technical specifications were verified, and it was recommended for deployment for air-quality improvement, temperature reduction and particulate carbon collection.

85.7%PM2.5 removed350 → 50 µg/m³, inlet to outlet
84.0%PM10 removed406 → 65 µg/m³, inlet to outlet
84.4%Total dust removed480 → 75 µg/m³, inlet to outlet
80.3%VOCs removed243 → 48 µg/m³, inlet to outlet
70%Lower PM2.5 in surrounding air350 → 105 µg/m³ around the unit within 48 hours
88%Fewer fine particlesParticles ≥ 0.3 µm, inlet to outlet
3.5°CCooler outlet air30.0°C in, 26.5°C out
9.9 gDust and carbon capturedIn 48 hours, weighed by the evaluators
300 CFM airflow verifiedOxygen improved by 0.5% (20.8% → 20.9%)Ozone at outlet held to 9 µg/m³Three-stage design verified on siteIndian Patent No. 422515
Request the full test reportFill in the enquiry form and choose “Independent Test Report” under service. Our team will share it with you.
The technology has demonstrated its effectiveness for optimising air quality.Independent third-party evaluation by an esteemed technology institute · Report CEED/CON/4487/2026 · November 2026

Ideal for

Where it is used

Traffic junctionsHighways and toll plazasBus and railway stationsSchool and college campusesHospitalsIndustrial estatesParks and public squaresCorporate campuses
View full technical specifications
TechnologyPatented air pollution filtration system (Indian Patent No. 422515, valid to 2042)
Purification stagesCyclone, coaxial corona discharge and activated carbon
Air flow300 CFM per unit
MonitoringPM2.5, PM10, O₂ and CO₂, online
Trunk size3 ft × 3 ft × 9.5 ft, with 8 ft diameter branches
WeightAbout 150 kg
Power230 V, 5 A; under 1 unit per day
Site needsAC supply, a 2.5 ft × 2.5 ft flat concrete base and an internet connection
By-productCollected dust and carbon, weighed and reported

Independently tested by an esteemed technology institute (November 2026): 85.7% PM2.5, 84.0% PM10 and 80.3% VOC removal from inlet to outlet. The full report is available on request.

See it in action

Photos and video

Impact parameters

Impact we measure and report

Every installation is tracked against clear, verifiable parameters so you can report outcomes to regulators, boards and CSR committees.

20

Trees’ worth of purification per unit

300 CFM of continuous street-level purification.

4

Parameters monitored live

PM2.5, PM10, O₂ and CO₂ on a dashboard.

Dust and carbon collected

Kilograms captured in the tray, weighed and reported.

Local air quality

Before and after readings around the site.

Policy & SDG alignment

Aligned with national priorities and global goals

UN Sustainable Development Goals

SDG3
Good health and well-being Less exposure to fine particulate pollution (target 3.9).
SDG11
Sustainable cities and communities Better air quality in cities (target 11.6).
SDG13
Climate action Captured carbon is collected and researched for reuse.
SDG9
Industry, innovation and infrastructure Patented, Made-in-India clean-air technology.

Central government policy

National Clean Air Programme (NCAP)

Supports cities working to reduce PM10 and PM2.5 levels.

Finance Commission air-quality grants

Million-plus cities can deploy measurable air-quality interventions.

Green Highways Policy, 2015

Complements roadside plantation at non-plantable points such as toll plazas.

Prime Minister’s vision

Mission LiFE

Healthier, more liveable cities.

Swachh Bharat

Clean air as part of clean cities.

Make in India

Patented Indian clean-air technology.

CSR alignment

Schedule VII (iv)

Environmental sustainability and ecological balance.

Schedule VII (i)

Preventive health care through cleaner air.

Testimonials

What our clients say

“We installed eTree at our central student quadrangle where foot traffic is highest. Beyond being a striking green installation, it creates a clean-air zone. Students sit and study under it, and the real-time display shows visible drops in PM2.5 and PM10 levels during peak hours.”

Dean of Infrastructure & Student Affairs, Educational Campus

“Reducing traffic emissions at congested road junctions is a key NCAP priority for our municipal corporation. The eTree units are an ideal decentralised intervention. Their filtration captures vehicle soot and particulate smog continuously without taking up large sidewalk space or needing heavy civil work.”

Executive Engineer, Smart City Development Corporation

Frequently asked questions

Questions about eTree Ambient Air Purifier

How does eTree purify air?

Air enters at the base and passes through a cyclone that removes coarse dust, a corona-discharge stage that captures fine particulates and carbon, and an activated-carbon stage that neutralises ozone. Clean air leaves at the top.

What does eTree monitor?

Each eTree tracks PM2.5, PM10, O₂ and CO₂ online, so you can see and report air quality around the unit.

How much power does eTree use?

About 0.3–0.5 units of electricity a day on a 230 V, 5 A supply.

Where can eTree be installed?

At traffic junctions, toll plazas, bus and railway stations, campuses, hospitals, parks and industrial estates. It needs a 2.5 ft square concrete base, power and internet.

Can eTree be funded through NCAP or CSR?

Yes. Cities can use NCAP and Finance Commission air-quality funds, and companies can fund eTree under CSR Schedule VII for environmental sustainability.

Get a proposal

Get an eTree proposal for your city or campus

Tell us your location and how many sites you want to cover. We will recommend the number of units and send a proposal with monitoring and maintenance.

  • ✓ Site and air-quality assessment
  • ✓ Number of units and placement
  • ✓ Live monitoring dashboard
  • ✓ NCAP, CSR and green fund guidance
